3 Axles End Dump Semi Trailer

Payload:
60 - 80tons, customized
side panel:
4m m flat plate NM450, 2000mm high
Axles:
3-6 Axle, 13T
Rim:
9.00-22.5 12pcs
Wheelbase(mm):
9000*2500*3600mm
Buy The Truck
Overview
04
3 AXLES END DUMP SEMI TRAILER

3 Axles End Dump Semi Trailer is a specially designed semi-trailer which combines the convenience of container transport and the practicality of self-unloading function. This kind of semi-trailer is not only capable of transporting containers safely and efficiently like ordinary container semi-trailers, but also has the ability to unload containers or goods automatically.

02
3 AXLES END DUMP SEMI TRAILER

3 Axles End Dump Semi Trailer are usually equipped with special unloading devices, such as hydraulic lifting system, tilting mechanism or rotating device, etc. These devices can be activated when needed to make containers or cargoes unloaded automatically from semi-trailers without manual labour or use of other lifting equipment. Chinese trailers for sale semi dump trailer design greatly improves loading and unloading efficiency, reduces labour costs, and lowers the risk of cargo damage due to improper manual handling.

01
3 AXLES END DUMP SEMI TRAILER

3 Axles End Dump Semi Trailer end dump truck has a wide range of application scenarios, especially suitable for occasions where frequent loading and unloading of containers or goods is required, such as harbours, wharves, logistic parks and construction sites. In these occasions, sinotruk howo trailer Chinese trailers for sale end dump semi trailer can significantly improve the transport efficiency, shorten the loading and unloading time, and enhance the overall operational efficiency.

Specifications
Product Name 3 AXLES END DUMP SEMI TRAILER
Function Transport heavy  Stone and Sand
Overall dimension 9000x2500x3600mm
Loading weight 60000KGS to 80000KGS
Main beam Material is Q345B, The height of the beam is 500 mm, upper plate is16mm,down plate is 18mm,middle plate is 10mm.
Side beam 22mm channel steel
Traction pin JOST Brand, optional 2″ or 3.5″
Land gear Standard 28ton
Axle 13ton for each axle
Axle brand FUWA Brand axle
Suspension type 3 axle mechanical suspension
Leaf spring 10/10/10 90mm*13mm*10pcs
Rim 9.00-22.5 12pcs
Tire 1200R20 triangle brand
Tire quantity 12 units
Box Size Bottom 8MM Size 6MM
Valve WABCO VALVE
Brake Chamber 6 big chamber brake system
Tool box 1 unit 1m*0.5m*0.5m
Spare wheel carrier 2 units
Side marker lamp LED type
Voltage 24V
Receptacle 7ways (7 wire harness)
