Howo 4x2 Flatbed Light Truck

Model:

ZZ1047D3415C1

Engine:

116HP

Loading Capicity:

5Ton

Request for Price

Overview

Sinotruk Howo 4x2 Flatbed Truck: A versatile transport tool

A star product of Sinotruk, the Sinotruk Howo 4×2 Flatbed Light Truck, with its 5-ton load capacity , is ideal for urban and rural distribution and short- and medium-distance transport.with 116 horsepower engien, and 6 speed transmission, it maintains stable output even in mountainous terrain.

Sinotruk Howo 4x2 Flatbed Truck: Intelligent and reliable

The Sinotruk Howo 4×2 Light Truck features a four-point suspension cab and airbag-assisted shock-absorbing seats, reducing fatigue by 40% after eight hours of continuous driving.

Specifications

ENGINE	Manufacturer: YUNEI
	Diesel:4-strote direct injection diesel engine
	Engine model: YN4102QBZL engine, Euro II emission standard, water-cooled, four strokes, 4 cylinders in line with water cooling. Turbocharged and intercooling, directly injection
	Max output:116HP
	Displacement:3.298L
CLUTCH	Φ300 diaphragm single-plate dry coil-spring clutch.
TRANSIMISSION	Model: WLY6T100, 6forward & 1reverse
FRONT AXLE	2.4T Forging I beam
REAR AXLE	4.2T Pressed welding axle housing
STEERING	Left hand driving
BRAKING SYSTEM	service brake: dual circuit compressed air brake Parking brake(emergency brake):spring energy, compressed air operating on rear wheels
TIRES	7.00R16 Radial Tire with one spare tire.
CAB	1880 one and half row cabin, with A/C
ELECTRICAL SYSTEM	Operating voltage: 24V, negative grounded Starter: 6 kW Alternator: 28V, 55A batteries: 2 x 12V, 120 Ah
INSTRUMENT PANEL	Active check control with indicators, with this instrument the daily manual checks on the vehicles and combined indicators of compressed pressure, coolant temperature, engine oil pressure and battery charging
DIMENSION IN (MM)	Wheel base	3360
	Front/ Rear wheel track	1605/1520
	Front/ Rear overhang	1160/1475
	Approach/ Departure angle(°)	20/18
	Dimension(Lx W x H)（unloaded）	6995×2100*2650

Gallery

Test data shows that the Sinotruk Howo 4×2 Flatbed Truck boasts a fuel consumption of just 18L per 100km and a maintenance interval of 50,000km. Currently, the Sinotruk Howo 4×2 Flatbed Truck is widely used in express delivery routes, cold chain transit, and other applications, and has maintained a top-three ranking in customer satisfaction for three consecutive years.

FAQ

Are you a dealer or a factory?

We are the official SINOTRUK factory.

I want to ship the truck by container. Is it possible?

Yes, it is possible. However, the truck needs to be disassembled for loading, and you will need to reinstall it in your country.

How is the product quality?

All trucks are original SINOTRUK products, and the quality is 100% guaranteed.

I want to become your agent in my country. Is that acceptable?

Yes, it is possible. If your purchase volume is large, we can consider it. A yearly order of 200 units is acceptable.

How is your company's service, especially after-sales service?

SINOTRUK has many after-sales service stations worldwide, and spare parts are widely available in local markets.

What are your payment terms?

You may choose 30% prepaid and 70% paid before delivery.

What is the production time?

Delivery time: within 30 working days after receiving the deposit.
