sinotruk howo 6x4 water truck

Sinotruk Howo 6x4 Water Truck

Fuel Tank:

400L

Wheel base:

1800+ 4600+ 1350

Make:

WICHAI

(L*W*H)(mm):

9800*2500*3350mm

Horse Power:

310HP 340HP 375HP 400HP

Buy The Truck

SINOTRUK HOWO 6X4 WATER TRUCK

Engine: SINOTRUK WD615 series diesel engine, Euro II/Euro III emission standard (optional)

Power output: 266–371 HP

Transmission: Manual, 10-speed gearbox for strong traction and fuel efficiency

Tank material: High-quality carbon steel (optional stainless steel or anti-corrosion lining)

Tank capacity: 15,000–20,000 liters (customizable)

Internal baffles: Wave-plate design to reduce water movement during driving

SINOTRUK HOWO 6X4 WATER TRUCK

High-performance water pump with strong suction and discharge capability

Front, rear, and side spray nozzles for road washing and dust suppression

Rear working platform with water cannon for long-distance spraying (up to 28 meters)

Urban road cleaning and maintenance

Dust suppression in mining or construction sites

Agricultural irrigation and landscaping projects

Emergency water transportation and fire-fighting assistance

SINOTRUK HOWO 6X4 WATER TRUCK

Advantages:

Rugged chassis for long service life in tough environments

Flexible spraying modes to meet various needs

Easy operation and maintenance with widely available spare parts

Customizable tank size, spraying system, and pump configuration

SINOTRUK HOWO 6X4 WATER TRUCK
Chassis Model	ZZ1257N4347D1B
Driving Type	LHD (RHD is optional)
Cabin	HW76 cab, with one sleeper, two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine	Make: WICHAI
	Diesel 4-stroke direct injection diesel engine
	Engine model: WP12.400E201, Euro II, 400 HP
	6-cylinder in-line with water cooling, turbo-charging and intercooling
	Displacement: 11.596 L
Transmission	HW19710, 10F & 2R
Transmission	Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, model ZF8118, hydraulic steering with power assistance
Front Axle	VGD95, 1×9000 KGS
Front Axle	Steering with double T-cross section beam
Rear Axle	HC16, 2×16000 KGS
	Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.
	Ratio:4.42
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members
	Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
	Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake
	Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
	Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded
	Starter: 24 V, 5.4 Kw
	Alternator: 3-phase, 28 V, 1500 W
	Batteries: 2 x 12 V, 165 Ah
	Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres	12.00R20, Radial tires with one spare tire
Fuel Tank	400L
Tank Body	Capacity: 20 Cubic Meters, 20,000 Liters
	Front and Rear sprinkling system
	High Press Water Jet. Turning Lights
Overall Dimension	980025003350mm

Sinotruk Howo 6x4 Water Truck
