Sitrak C7H 6x4 540hp Tractor Truck

Model:

ZZ4256V364HE

Series:

Sitrak C7H

Engine model:

MC13.54-30, MAN license

Engine variant power:

540HP

Transmission:

Automated

Request for Price

Overview

Sitrak C7H 6×4 540 Tractor Truck-1

Sitrak C7H 6x4 540hp Tractor Truck Features: Powerful Performance, Heavy-Duty Pioneer

As a high-end model under Sinotruk Group, the Sinotruk Sitrak C7H 6×4 540hp Tractor Truck is equipped with a MAN MC13 engine, delivering a powerful 540 horsepower output paired with a 16-speed AMT transmission, effortlessly handling complex terrain such as mountainous and high-altitude regions. The Sinotruk Sitrak C7H 6×4 540hp Tractor Truck’s modular design achieves a B10 lifespan exceeding 1.5 million kilometers, making it a reliable partner for long-haul freight transportation.

Sitrak C7H 6×4 540 Tractor Truck-2

Sitrak C7H 6x4 540hp Tractor Truck: Intelligent Driving Control, Safety Always by Your Side

The Sitrak C7H 6×4 540hp Tractor Truck comes standard with AEBS automatic emergency braking and LDWS lane departure warning. The cab features patented four-point suspension technology, combined with air-cushioned seats, effectively reducing fatigue during long-distance driving. The Sitrak C7H 6×4 540hp Tractor Truck is equipped with an intelligent fuel-saving system, achieving a fuel consumption reduction of 8%-12% per 100 kilometers compared to similar products.

Specifications

Equipment

Built in high strength steel, 70º tilting with electric lift, 3
speed windshield wipers, dashboard with on-board computer, laminated windshield, driver’s seat with
air suspension, adjustable windshield protector outside the cabin, AM/FM radio with MP5, height and depth adjustable steering wheel, air horn, air conditioning with digital climate control, electric windows, 4 electric mirrors, central door locking, auxiliary reading lighting for beds and driver’s seat, with VDO MTCO1324 tachograph.

Engine

Brand and Model:  MC13.54-50 Common Rail EURO V
Net Power KW / HP @ rpm:  400Kw / 540 HP at 1900 rpm
Displacement:  12,419 cc
Stroke (mm):  166
Cylinder diameter (mm):  126
Torque (Nm/rpm):  2,500 Nm at 1,050 -1,350 Rpm
Fuel:  Diesel
Fuel Consumption (g/Kwh):  ≤188

Dimensions

Support bases:  Ladder type – Parallel “U” profile with MAN section 270x85x8 mm
Sizes (Length x Width x Height) (mm):  6,895 x 2,496 x 3,980 Dimensions (mm)
Wheelbase:  3,200 + 1,400 mm
Rear Suspension:  Pneumatic 8 bladders CONTITECH + ECAS WABCO
Angle of entry : 19º
Angle of exit : 32º

Weight and capacity

Vehicle Type :  Truck Tractor
Engine Power:  540 HP
Traction:  6×2 / 6×4
Weight (Kg):  8300 / 8900
Fifth wheel / pin measurement:  JOST / 50mm

Gallery

Tailored for time-sensitive industries such as cold chain logistics and express delivery, the Sitrak C7H 6×4 540hp Tractor Truck features a dual fuel tank configuration of 600L + 400L, offering a range exceeding 3,000 kilometers. Its lightweight design keeps the vehicle’s curb weight at just 8.5 tons, paired with a 3.083 low-gear ratio rear axle, achieving a perfect balance between load-carrying capacity and fuel efficiency.

Sitrak C7H 6×4 540 Tractor Truck-5

Sitrak C7H 6×4 540 Tractor Truck-4

Sitrak C7H 6×4 540 Tractor Truck-2

Sitrak C7H 6×4 540 Tractor Truck-1

Sitrak C7H 6×4 430 Tractor Truck-5

FAQ

Are you a dealer or a factory?

We are the official SINOTRUK factory.

I want to ship the truck by container. Is it possible?

Yes, it is possible. However, the truck needs to be disassembled for loading, and you will need to reinstall it in your country.

How is the product quality?

All trucks are original SINOTRUK products, and the quality is 100% guaranteed.

I want to become your agent in my country. Is that acceptable?

Yes, it is possible. If your purchase volume is large, we can consider it. A yearly order of 200 units is acceptable.

How is your company's service, especially after-sales service?

SINOTRUK has many after-sales service stations worldwide, and spare parts are widely available in local markets.

What are your payment terms?

You may choose 30% prepaid and 70% paid before delivery.

What is the production time?

Delivery time: within 30 working days after receiving the deposit.
